ML-TR (5 CCT Series)

ML-TR (5 CCT Series)

High Output LED Troffer Series with 5CCT

  • certifications
  • certifications
  • certifications
  • certifications
  • certifications

Available in two convenient sizes 2'X2'ft, and 2'X4'ft dimensions. This versatile LED Troffer family is designed to meet the demands of various commercial applications. With power options up to 40W and 72W, and selectable color temperatures ranging from 3000K to 6500K, these troffers provide customizable illumination to suit any environment.

Constructed with a durable, powder-coated steel housing, each fixture is DLC and UL listed, ensuring both quality and energy efficiency. A 5-year limited warranty offers added peace of mind.

For added functionality, an emergency battery backup option is available, providing up to 90 minutes of illumination in case of power loss.

View full details

Applications:

  • Schools, Retail stores, QSR environments, Offices, Hospitals and other work environments.

Key Features:

  • Two sizes in this panel family
  • Universal input voltage (120-277V)
  • CCT and Color Adjustable
  • Emergency option available 90 mins Battery Backup
  • Slim profile with best in class lumens performance
  • Prismatic frosted lens for great glare control
  • 2500/3125/3750/4375/5000 Lumens
  • 3750/5000/6250/7500/9000 Lumens
  • Powder painted white steel gauge housing
  • Input Power of max. 40W or 72W
  • 3000K/3500K/4000K/5000K/6500K color selectable Daylight White Color Output
  • UL Listed
  • 5 Year Warranty

Specifications

  • INPUT VOLTAGE 120-277V
  • INPUT WATTAGE 20W/25W/30W/35W/40W
    30W/40W/50W/60W/72W
  • LUMENS 5000lms/9000lms
  • RATED LIFE >50,000hrs
  • OPERATING TEMPERATURE -30 °F to 130 °F
  • CERTIFICATION UL, Wet Locations, DLC Premium
  • CRI >80
  • AVAILABLE CCT 3K/3.5K/4K/5K/6.5K
  • IP RATING IP43
  • DIMENSION 8.8" x 8.8" x 3.3"
    10.6" x 10.6" x 3.7"
    12.8" x 12.8" x 3.85"
  • WEIGHT 5.58 lbs
  • MODEL NUMBER ML-TR-22-40WT-5CCT-UV
    ML-TR-22-40WT-5CCT-UV-EM
    ML-TR-24-72WT-5CCT-UV
    ML-TR-24-72WT-5CCT-UV-EM

Download

  • Model No.
  • ML-TR-22-40WT-5CCT-UV
  • ML-TR-22-40WT-5CCT-UV-EM
  • ML-TR-24-72WT-5CCT-UV
  • ML-TR-24-72WT-5CCT-UV-EM
  • Wattage
  • 20/25/30/35/40W
  • 20/25/30/35/40W
  • 30/40/50/60/72W
  • 30/40/50/60/72W
  • CCT
  • 3K/3.5K/4K/5K/6.5K
  • 3K/3.5K/4K/5K/6.5K
  • 3K/3.5K/4K/5K/6.5K
  • 3K/3.5K/4K/5K/6.5K
  • Lumens
  • 2500/3125/3750/7375/5000 lms
  • 2500/3125/3750/7375/5000 lms
  • 3750/5000/6250/7500/9000 lms
  • 3750/5000/6250/7500/9000 lms

ML-TR-22-40WT-5CCT-UV

ML-TR-22-40WT-5CCT-UV-EM

ML-TR-24-72WT-5CCT-UV

ML-TR-24-72WT-5CCT-UV-EM
