ML-DL-S Series

ML-DL-S Series

Surface Downlight

  • certifications
  • certifications
  • certifications

Slim profile LED surface mount is available in both round and square sizes.  Beautiful uniform light provides a glare-free lighting effect, ensuring great comfortability for homeowners.  Product is compatible with many junction boxes.   Disc surface mount LED downlight in 5 inch and 7 inch and 9 inch are low profile.

View full details

Applications:

  • Homes, townhomes, apartments, offices, schools

Key Features:

  • Single input voltage (120V)
  • Comparable to a 75W incandescent bulb
  • Advanced industrial grade polycarbonate lens
  • 688 lumens in 5 inch
  • 1215 lumens in 7 inch
  • 1426 lumens in 9 inch
  • Steel housing
  • 10 Watts in 5 inch downlight
  • 15 Watts in 7 inch downlight
  • 18 Watts in 9 inch downlight
  • Multi CCT (5 CCT) Color Output (2700K/3000K/3500K/4000K/5000K)
  • ETL Listed
  • 5 Year Warranty

Specifications

  • INPUT VOLTAGE 120V
  • INPUT WATTAGE 5" 10W
    7" 15W
    9" 18W
  • LUMENS 5" 710 lms
    7" 1241lms
    9" 1460 lms
  • EFFICACY 71 lm/w
    83 lm/w
    81 lm/w
  • RATED LIFE >50,000hrs
  • OPERATING TEMPERATURE -30 °F to 104 °F
  • CERTIFICATION ETL
  • EQUAL TO 75W Incandescent
  • CRI >90
  • AVAILABLE CCT 2700K/3000K/4000K/5000K
  • DIMENSION
  • WEIGHT 2.5lbs
  • PHOTOCONTROL No
  • MODEL NUMBER ML-DL-5S-10WT-5CCT-120V
  • MODEL NUMBER ML-DL-7S-15WT-5CCT-120V
  • MODEL NUMBER ML-DL-9S-18WT-5CCT-120V

Download

  • Model No.
  • ML-DL-5S-10WT-5CCT-120
  • ML-DL-7S-15WT-5CCT-120
  • ML-DL-9S-18WT-5CCT-120
  • Wattage
  • 10W
  • 15W
  • 18W
  • CCT
  • 5 CCT (2.7K/3K/3.5K/4K/5K)
  • 5 CCT (2.7K/3K/3.5K/4K/5K)
  • 5 CCT (2.7K/3K/3.5K/4K/5K)
  • Lumens
  • 710 lms
  • 1241 lms
  • 1460 lms

ML-DL-xS Series
