ML-GC-59XX Series

ML-GC-59XX Series

  • certifications
  • certifications
  • certifications
  • certifications
  • certifications
Replaces 100~250-watt high intensity discharge (HID). 40W-60W-80W LED Garage and Canopy Light with CCT and Wattage Selectable.  Industrial strength polycarbonate lens with diamond cut prismatic distribution provide minimal glare to customers.  3000K/4000K/5000K Dark bronze, DLC and UL Listed, 5-year limited warranty
View full details

Applications:

  • Garage & Canopy Light,  Industrial Site Lighting

Key Features:

  • Universal input voltage (120-277V)
  • Comparable to a 150W metal-halide light
  • Advanced optic system for rebate eligibility
  • 6313 Lumens
  • Dark bronze aluminum housing
  • Input Power of 57 Watts
  • 5000K Daylight White Color Output
  • UL Listed and suitable for wet locations
  • 5 Year Warranty

Specifications

  • INPUT VOLTAGE 120-277V
  • INPUT WATTAGE 14W/25W/37W/42W
    26W/49W/72W/83W/37W/55W/61W
  • LUMENS 5574 lms
    7707 lms
    10815 lms
  • RATED LIFE >50,000hrs
  • DIMMABLE 0-10V
  • OPERATING TEMPERATURE -30 °F to 104 °F
  • CERTIFICATION UL, Wet Locations, DLC Premium
  • EQUAL TO 100W/150W/250W Metal Halide
  • CRI >70
  • AVAILABLE CCT 3000K/4000K/5000K
  • IP RATING IP65
  • DIMENSION 8.8" x 8.8" x 3.8"
    10.6" x10.6" x 4.2"
    12.8" x 12.8" x 4.4"
  • WEIGHT 5.58 lbs
    8.8 lbs
    12.5 lbs
  • MODEL NUMBER ML-GC-5928-45WT-345K-UV
    ML-GC-5948-60WT-345K-UV
    ML-GC-5968-85WT-345K-UV

Download

  • Model No.
  • ML-GC-5928-45WT-345K-UV
  • ML-GC-5948-60WT-345K-UV
  • ML-GC-5968-85WT-345K-UV
  • Wattage
  • 14W/25W/37W/42W
  • 19W/37W/55W/61W
  • 26W/49W/72W/83W
  • CCT
  • 3000K/4000K/5000K
  • Lumens
  • 5574 lms
  • 7707 lms
  • 10815 lms

ML-GC-5928-45WT-345K-UV

ML-GC-5948-60WT-345K-UV

ML-GC-5968-85WT-345K-UV
