4" and 6" Disk Light

  • certifications
  • certifications
  • certifications

This versatile downlight offers a flexible lighting solution, ideal for surface mounting and retrofit installations. It is crafted with a durable, high-quality steel body and a frosted PC diffuser, blending durability with a modern aesthetic. The advanced color-tunable technology allows users to select from five light temperatures—2700K, 3000K, 3500K, 4000K, or 5000K—to perfectly suit any space or mood.

Designed with wet-location certification, this downlight is suitable for high-moisture environments such as bathrooms, laundry rooms, porches, and garage work areas. Its installation flexibility supports multiple apertures, making it compatible with 5- or 6-inch recessed cans, as well as 2.75–13.5-inch and 4-inch junction boxes, making it an excellent choice for under soffits and shower installations. Additionally, it works with most triac dimmers to deliver smooth dimming from 100% to 5%, allowing users to customize brightness to their preference.

Upgrade your lighting with this functional, stylish, and adaptable solution.


View full details

Applications:

  • Homes, townhomes, apartments, offices, schools

Key Features:

  • Single input voltage (120V)
  • Comparable to a 75W incandescent bulb
  • Dimming compatible with most triac dimmers
  • CRI90
  • 1100 lumens in 6 inch
  • 625 lumens in 4 inch
  • Input Power of 15 Watts in 6 inch downlight
  • Input Power of 10 Watts in 4 inch downlight
  • Multi CCT 2700K/3000K/3500K/4000L/5000K Color Output
  • ETL Listed
  • 5 Year Warranty

Specifications

  • INPUT VOLTAGE 120V
  • INPUT WATTAGE 10W《br> 5W
  • LUMENS 625 lms
    1100 lms
  • EFFICACY 63lm/w
    73 lm/w
  • RATED LIFE >50,000hrs
  • OPERATING TEMPERATURE -30 °F to 104 °F
  • CERTIFICATION ETL
  • EQUAL TO 75W Incandescent
  • CRI 90
  • AVAILABLE CCT 2700K/3000K/3500k/4000K/5000K
    2700K/3000K/3500k/4000K/5000K
  • DIMENSION 5.88" x 5.88" x0.91"
    7.3" x 7.3" x 1.1"
  • WEIGHT 2.0 lbs
    2.5lbs
  • PHOTOCONTROL No
  • MODEL NUMBER ML-DL-4-10WT-5CCT-120
    ML-DL-6-15WT-5CCT-120

Download

  • Model No.
  • ML-DL-4-10W-5CCT-120
  • ML-DL-6-15W-5CCT-120
  • Wattage
  • 10W
  • 15W
  • CCT
  • Multi CCT (2.7K/3K/3.5K/4K/5K)
  • Multi CCT (2.7K/3K/3.5K/4K/5K)
  • Lumens
  • 625 lms
  • 1100 lms

ML-DL-4-10W-5CCT-120

ML-DL-6-15W-5CCT-120
